IoT Sensors For UBTHPI-4G Connected Cloud Platform Pressure And Humidity Measurement
| Place of Origin | Beijing, China |
|---|---|
| Brand Name | UNIVO |
| Model Number | UBTHPI-4G |
| Price | $51.00 - $63.00/sets |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Features | Connected Cloud Platform | Series | UBTHPI-4G |
|---|---|---|---|
| Mounting Type | - | Description | Fire Extinguishers IoT Sensors, IoT Sensors |
| Manufacturing Date Code | 2024 | Type | Temperature Sensor |
| Usage | Temperature And Humidity Measurement | Theory | - |
| Range | 0~± 100KPa | Humidity Range | 0-99% RH |
| Inclination Range | ± 90 ° (X; Y; Z Three-axis) | Pressure Form | Gauge Pressure/absolute Pressure |
| Highlight | connected cloud platform iot sensors,ubthpi-4g iot sensors,temperature and humidity measurement iot sensors |
||
Product Description
Products Description
Industry
fire protection
nuclear power
energy
petroleum
Smart IoT
fire protection
nuclear power
energy
petroleum
Smart IoT
Product Paramenters
| project | parameter | project | parameter |
| Measurement medium | Gas/liquid (compatible with process connections) | Battery specifications | 14250 * 2; 3.6VDC/2400mAh; Replaceable |
| Pressure form | Gauge pressure/absolute pressure | service life | ≥ 1 million times |
| Pressure range | 0-0.6/1.6/5/10/20/30/50/60 (MPa); | Battery life | ≥ 3 years/collection frequency 8 hours/time |
| | 0~10/20/30/50/100/300/500/600 (KPa) | Medium temperature | -20-80 ℃ |
| | 100KPa~10KPa~5MPa; | ambient temperature | -40~+70 ℃ |
| | ± 10KPa to ± 100KPa; | Inspection time | 0-9 hours, 00-59 minutes/time |
| Temperature range | -40~+70 ℃ | Upload time | 01-99 times inspection time |
| Humidity range | 0-99% RH | Overload pressure | 150% FS |
| Inclination range | ± 90 ° (X; Y; Z three-axis) | Destruction pressure | 3 times the range; |
| Comprehensive accuracy | Pressure: ± 0.5% FS; Temperature: ± 1 ℃ | Antenna mode | Built in installation free |
| | Humidity: ± 3% RH; Tilt angle: ± 1 ° | Protection level | IP67 |
| Communication type | Mobile 4G/SIM card replaceable | Process Connection | M10X1; G1/4; 1/4NPT; M20 * 1.5 can be customized by the user |
Details Images
Company Profile
Why Choose Us
Product packaging
FAQ
Q1. What are your packaging conditions? Answer: Usually, brown cardboard boxes are packaged with bubble bags inside to wrap the product. Q2. How long is your quotation valid? Answer: Our quotation is valid for 30 days. Q3. How is your delivery time? Answer: General standard type: 7-15 working days after confirming the order based on the quantity; Non standard types require communication and confirmation with us. Q4. What is your minimum order quantity? Answer: According to different product types, the cost varies and the minimum order quantity also varies. Please contact us for confirmation. Q5. How do you ensure good product quality? Answer: We have a complete quality control system; All of our products undergo a comprehensive inspection by the quality department before being shipped to customers. Q6. Can you produce based on samples? Answer: Yes, we can produce according to your samples or technical drawings. Q7. Can you accept OEM brands? Answer: Yes, we can accept OEM brands. Q8. How long is the warranty period for your product? Answer: Lifetime maintenance, 24 months of non human damage (calculated from the time of receipt), with free replacement if there are quality issues (damage caused by human factors, overload use, etc. are not within the warranty scope); Only material fees will be charged beyond the warranty period. Accessories and gifts are not covered by the warranty. Q9. How to deliver? Answer: For your convenience, we can send goods through DHL, TNT, UPS, SF, EMS, etc. for prepaid shipping, or use your own courier account to collect shipping fees. Q10. Can I take the sample? Answer: You can contact us to help you get the samples as soon as possible. Purchase guide To recommend you the most suitable sensor, please tell us below information. 1. Working temperature: -40~+125 °C ? 2. Test range? 3. Output: 4-20mA , RS485 or others? 4. Screw: G1/4, 1/4NPT, R1/4, M20*1.5? 5. Electrical connection: DIN43650, Packard, Direct lead? 6. Order quantity: ?
